Webinar Reflection: Stats for Data Visualization Part 1

Thank you to Makeover Monday‘s Eva Murray and Andy Kriebel for allowing me to grace their BrightTALK air waves with my love language of statistics yesterday! If you missed it, check out the recording.

webinar 1

With 180 school days and 5 classes (plus seminar once/week), you can imagine a typical U.S. high school math teacher has the opportunity to instruct/lead between 780 and 930 lectures each year. After 14 years teaching students in Atlanta-area schools (plus those student-teaching hours, and my time as a TA at LSU), I’ve instructed somewhere in the ballpark of 12,000 to 13,500 lessons in my lifetime.

So let’s be honest. Yesterday I was nervous to lead my very first webinar. After all, I depend on my gift of crowd-reading to determine the pace (and the tone) of a presentation. Luckily, I’m an expert at laughing at my own jokes so after the first few slides (and figuring out the delay), I felt comfortable. So Andy and Eva, I am ready for the next webinar on December 20th — Audience, y’all can sign up here.

Fun Fact: In 6th grade I was in the same math class as Andy Kriebel’s sister-in-law. It was also the only year I ever served time in in-school suspension (but remember, correlation doesn’t imply causation).

Webinar Questions and Answers

I was unable to get to all the questions asked on the webinar but rest assured I will do my best to field those here.

  1. Q: Can you provide the dataset? A: Here’s a link to the 4Runner data I used for most of the webinar. Let me know if you’d like any others.
  2. Q: Do you have the data that produced the cartoon in the beginning slide? A: A surprising number of people reproduced the data and the curves from the cartoon within hours of its release. Here is one person’s reproduction in R from this blog post
  3. Q: Do you have any videos on the basics of statistics? A: YES! My new favorite is Mr. Nystrom on YouTube, we use similar examples and he looks like he loves his job. For others, Google the specific topic along with the words “AP Statistics” for some of the best tutorials out there.
  4. Q: Could you explain about example A with r value -0.17, it seems as 0. A: The picture when r = -.17 is slightly negative — only slightly. This one is very tricky because we tend to think r = 0 if it’s not linear. But remember correlation is on a continuous scale of weak to positive – which means r = -.17 is still really, realAly weak. r = 0 is probably not very likely to be observed in real data unless the data creates a perfect square or circle, for example.
  5. Q: Question for Anna, does she also use Python, R, other stats tools? A: I am learning R! R-studio makes it easier. When I coach doctoral candidates on dissertation defense I use SPSS and Excel; one day I will learn Python. Of course, I am an expert on the TI-84. Stop laughing.TI84

6. Q: So with nonlinear regression [is it] better to put the prediction on the y-axis? A: With linear and nonlinear regression, the variable you want to predict will always be your y-axis (dependent) variable. That variable is always depicted with a y with a caret on top : y hatAnd it’s called “y-hat”

Other Helpful Links

If you haven’t had time to go through Andy’s Visual Vocabulary, take a look at the correlation section.

At the end of the webinar I recommended Bora Beran’s blog for fantastic explanations on Tableau’s modeling features. He has a statistics background and explains the technical in a clear, easy-to-understand format.

Don’t  forget to learn about residual plots if you are using regression to predict.

ice cube quote











How to Maximize Your Jellybeans

Milestone birthday this week.

As you’d imagine, I’ve been introspective. Am I living my best life? If I go out tomorrow, will I have regrets?

Regrets.

If you’ve asked my advice, I’ve recommended the adventure over the status-quo; the challenge over the straight path; the Soup Number 5 over the chicken fingers.  I’ve told you challenges grow you and discomfort makes you stronger. I come from personal experience — I’ve found regrets only inside the comfortable and the “supposed tos”.

My good friend Ericka lost her brother Daniel 5 years ago yesterday in a base-jumping accident. To honor his memory, Ericka posted a video he’d “have others watch for inspiration.”

So watch the video. And afterwards, if you want, you can keep reading this short post. But I won’t be offended if you choose to act on the emotions of the question, “What if you just had one more day? What are you going to do today?”

The day I had regrets.

Thursday, December 3rd 2015 started off with a strange, uncomfortable internal pain – which I chose to ignore. I was married to my schedule and my routine. So I went to the gym, got ready for work, dropped the kids off at their schools, and was at my school by 7:50am. A little voice told me, “Go to the hospital” as I walked into my classroom, but my duty was to my students, to my school, and to my responsibility to everyone else. “I’m sure it’s nothing,” I told my brain.

The pains would come and go every 5 minutes by that time. I taught (or, I tried to teach) my first period pre-calculus class. (I’ll never forget – it was a lesson on the Law of Sines ambiguous case. The “ASS” case. A tricky lesson involving logic, geometry, and effective cursing.) But I hit a point where the pain was so intense I’d have to stop the lesson and sit to take deep breaths. A student suggested I had appendicitis. And I remembered from natural childbirth the indication of real pain was the inability to walk or talk when it hit – and THIS is when I decided to step off that path of expectations of others and ask for help.

A coworker drove me to the hospital and a short while later, I was lying on a stretcher receiving an ultrasound on my abdomen. Stunned techs ran around me loudly relaying their confusion to each other. I’d had enough pain medicine to take the edge off the intensity, but at this point my stomach was beginning to protrude near my belly button and I understood the voices around me were screaming, “Emergency!”

When you think you are on your death bed, or when you’re given terrible news, or when you are in your last moments, I think the thoughts are the same: Have I said and done enough? Do the people I love know how I feel about them? Will my children remember me?

No regrets.

At 40 my regrets are now the words I didn’t say to the people I love.

But few are given a second chance to change how they live their life.

For the record, I had an intussusception – my small intestine telescoped into my large intestine and was sucked further and further until emergency surgery saved my life. It took a while for the doctors to solve my mystery because an intussusception is so rare in adults, especially in females. I was told at first it was most likely caused by colon cancer, though thankfully, the pathology report came back clear a few days later. After a full 6 days in the hospital and 26 staples down my abdomen, I was released into the arms of my loving family.

What if you just had one more day? What are you going to do today?

Rest in peace, Daniel Moore.

For what it’s worth … it’s never too late, or in my case too early, to be whoever you want to be. There’s no time limit. Start whenever you want. You can change or stay the same. There are no rules to this thing. We can make the best or the worst of it. I hope you make the best of it. I hope you see things that startle you. I hope you feel things you never felt before. I hope you meet people who have a different point of view. I hope you live a life you’re proud of, and if you’re not, I hope you have the courage to start all over again.

– F. Scott Fitzgerald, The Curious Case of Benjamin Button

The Analytics PAIN Part 3: How to Interpret P-Values with Linear Regression

You may find Part 1 and Part 2 interesting before heading into part 3, below.

p-value-statistics-meme

Interpreting Statistical Output and P-Values

To recap, you own Pearson’s Pizza and you’ve hired your nephew Lloyd to run the establishment. And since Lloyd is not much of a math whiz, you’ve decided to help him learn some statistics based on pizza prices.

When we left off, you and Lloyd realized that, despite a strong correlation and high R-Squared value, the residual plot suggests that predicting pizza prices from toppings will become less and less accurate as the number of toppings increase:

Shiny Residual Plot 2

A clear, distinct pattern in a residual plot is a red flag

Looking back at the original scatterplot and software output, Lloyd protests, “But the p-value is significant. It’s less than 0.0001.”

hold my beer

watch this



pizza4

The original software output. What does it all mean?



Doesn’t a small p-value imply that our model is a go?

freddie

A crash course on hypothesis testing

In Pearson Pizza’s back room, you’ve got two pool tables and a couple of slot machines (which may or may not be legal). One day, a tall, serious man saunters in, slaps down 100 quid and challenges (in an British accent), “My name is Ronnie O’Sullivan. That’s right. THE. Ronnie O’Sullivan.”

You throw the name into the Google and find out the world’s best snooker player just challenged you to a game of pool.

Then something interesting happens. YOU win.

Suddenly, you wonder, is this guy really who he says he is?

Because the likelihood of you winning this pool challenge to THE Ronnie O’Sullivan is slim to none IF he is, indeed, THE Ronnie O’Sullivan (the world’s best snooker player).

Beating this guy is SIGNIFICANT in that it challenges the claim that he is who he claims he is:

You aren’t SUPPOSED to beat THE Ronnie O’Sullivan – you can’t even beat Lloyd.

But you did beat this guy, whoever he claims to be.

So, in the end, you decide this man was an impostor, NOT Ronnie O’Sullivan.

In this scenario:

The claim (or “null hypothesis”): “This man is Ronnie O’Sullivan” you have no reason to question him – you’ve never even heard of snooker

The alternative claim (or “alternative hypothesis”): “This man is NOT Ronnie O’Sullivan”

The p-value: The likelihood you beat the world’s best snooker player assuming he is, in fact, the real Ronnie O’Sullivan.

Therefore, the p-value is the likelihood an observed outcome (at least as extreme) would occur if the claim were true. A small p-value can cast doubt on the legitimacy of the claim – chances you could beat Ronnie O’Sullivan in a game of pool are slim to none so it is MORE likely he is not Ronnie O’Sullivan. Still puzzled? Here’s a clever video explanation.

Some mathy stuff to consider

The intention of this post is to tie the meaning of this p-value to your decision, in the simplest terms I can find. I am leaving out a great deal of theory behind the sampling distribution of the regression coefficients – but I would be happy to explain it offline. What you do need to understand, however, is your data set is just a sample, a subset, from an unknown population. The p-value output is based on your observed sample statistics in this one particular sample while the variation is tied to a distribution of all possible samples of the same size (a theoretical model). Another sample would indeed produce a different outcome, and therefore a different p-value.

The hypothesis our software is testing

The output below gives a great deal of insight into the regression model used on the pizza data. The statistic du jour for the linear model is the p-value you always see in a Tableau regression output: The p-value testing the SLOPE of the line.

Therefore, a significant or insignificant p-value is tied to the SLOPE of your model.

Recall, the slope of the line tells you how much the pizza price changes for every topping ordered. Slope is a reflection of the relationship of the variables you’re studying. Before you continue reading, you explain to Lloyd that a slope of 0 means, “There is no relationship/association between the number of toppings and the price of the pizza.”

Tableau Regression Output

Zoom into that last little portion – and look at the numbers in red below:

Panes Line Coefficients
Row Column p-value DF Term Value StdErr t-value p-value
Pizza Price
Toppings
< 0.0001
19
Toppings
1.25
0.0993399
12.5831
< 0.0001
intercept
15
0.362738
41.3521
< 0.0001

In this scenario:

The claim: “There is no association between number of toppings ordered and the price of the pizza.” Or, the slope is zero (0).

The alternative claim: “There is an association between the number of toppings ordered and the price of the pizza.” In this case, the slope is not zero.*

The p-value = Assuming there is no relationship between number of toppings and price of pizza, the likelihood of obtaining a slope of  at least $1.25 per topping is less than .01%.

The p-value is very small** — A slope of at least $1.25 would happen only .01% of the time just by chance. This small p-value means you have evidence of a relationship between number of toppings and the price of a pizza.

What the P-Value is NOT

  • The p-value is not the probability the null hypothesis is false – it is not the likelihood of a relationship between number of toppings and the price of pizza.
  • The p-value is not evidence we have a good linear model – remember, it’s only testing a relationship between the two variables (slope) based on one sample.
  • A high p-value does not necessarily mean there is no relationship between pizza price and number of toppings – when dealing in samples, chance variability (differences) and bias is present, leading to erroneous conclusions.
  • A statistically significant p-value does not necessarily mean the slope of the population data is not 0 – see the last bullet point. By chance, your sample data may be “off” from the full population data.

The P-Value is Not a Green Light

archer

The p-value here gives evidence of a relationship between the number of toppings ordered and the price of the pizza – which was already determined in part 1. (If you want to get technical, the correlation coefficient R is used in the formula to calculate slope.)

Applying a regression line for prediction requires the examination of all parts of the model. The p-value given merely reflects a significant slope — recall there is additional error (residuals) to consider and outside variables acting on one or both of the variables.

Ultimately, Pearson’s Pizza CAN apply the linear model to predict pizza prices from number of toppings. But only within reason. You decide not to predict for pizza prices when more than 5 toppings are chosen because, based on the residual plot, the prediction error is too great and the variation may ultimately hurt long-term budget predictions.

In a real business use case, the p-value, R-Squared, and residual plots can only aid in logical decision-making. Lloyd now realizes, thanks to your expertise, that using data output just to say he’s “data-driven” without proper attention to detail and common sense is unwise.

Statistical methods can be powerful tools for uncovering significant conclusions; however, with great power comes great responsibility.

p_values

Note: This cartoon uses sarcasm to poke fun at blindly following p-values.

—Anna Foard is a Business Development Consultant at Velocity Group



*Note this is an automatic 2-tailed test. Technically it is testing for a slope at least $1.25 AND at most -$1.25. For a 1-tailed test (looking only for greater than $1.25, for example) divide the p-value output by 2. For more information on the t-value, df, and standard error I’ve included additional notes and links at the bottom of this post.

**How small is small? Depends on the nature of what you are testing and your tolerance for “false negatives” or “false positives”. It is generally accepted practice in social sciences to consider a p-value small if it is under 0.05, meaning an observation at least as extreme would occur 5% of the time by chance if the claim were true.

More information on t-value, df:

For those curious about the t-value, this statistic is also called the “critical value” or “test statistic”. This value is like a z-score, but relies on the Student’s t-distribution. In other words, the t-value is a standardized value indicating how far a slope of “1.25” will fall from the hypothesized mean of 0, taking into account sample size and variation (standard error).

In t-tests for regression, degrees of freedom (df) is calculated by subtracting the number of parameters being estimated from the sample size. In this example, there are 21 – 2 degrees of freedom because we started with 21 independent points, and there are two parameters to estimate, slope and y-intercept.

Degrees of freedom (df) represents the amount of independent information available. For this example, n = 21 because we had 21 pieces of independent information. But since we used one piece of information to calculate slope and another to calculate the y-intercept, there are now n – 2 or 19 pieces of information left to calculate the variation in the model, and therefore the appropriate t-value.

The Analytics PAIN Part 2: Least-Squares Regression Lines and Residuals

Haven’t read Part One of this series? Click here.

The Context

You are the sole proprietor of Pearson’s Pizza, a local pizza shop. Out of nepotism and despite his weak math skills, you’ve hired your nephew Lloyd to run the joint. And because you want your business to succeed, you decide this is a good time to strengthen your stats knowledge while you teach Lloyd – after all,

“In learning you will teach, and in teaching you will learn.”

– Latin Proverb and Phil Collins

Your pizzas are priced as follows:

Cheese pizza (no toppings): $15

Additional toppings: $1/each for regular, $1.50 for premium

When we left off, you and Lloyd were exploring the relationship between the number of toppings to the pizza price using a sample of possible scenarios.

pizza scatter

The scatterplot of Pizza Price vs. Number of Toppings: As the number of toppings increase, price of the pizza increases.

The Purpose(s) of a “Regression” Line

When investigating data sets of two continuous, numerical variables, a scatterplot is the typical go-to graph of choice. (See Daniel Zvinca’s article for more on this, and other options.)

So. When do we throw in a “line of best fit”? The answer to that question may surprise you:

A “line of best” fit, a regression line, is used to: (1) assess the relationship between two continuous variables that may respond or interact with each other (2) predict the value of y based on the value of x.

In other words, a regression line may not add value to Lloyd’s visualization if it won’t help him predict pizza prices from the number of toppings ordered.

pizza4

The equation: pizza price = 1.25*Toppings +15

Recall the slope of the line above says that for every additional topping ordered the price of the pizza will increase by $1.25.

In the last post you discussed some higher-order concepts with Lloyd, like the correlation coefficient (R) and R-Squared. Using the data above, you said, “89.3% of the variability (differences) in pizza prices can be explained by the number of toppings.” Which also means 10.7% of the variability can be explained by other variables, in this case the two types of toppings.

Since there is a high R-Squared value, does Pearson’s Pizza have a solid model for prediction purposes? Before you answer, consider the logic behind “least-squares regression.”

Least-Squares Regression

You and Lloyd now understand that “trend lines”, “lines-of-best-fit”, and “regression lines” are all different ways of saying, “prediction lines.”

The least-squares regression line, the most common type of prediction line, uses regression to minimize the sum of the squared vertical distances from each observation (each point) to the regression line. These vertical distances, called residuals, are found simply by subtracting the predicted pizza price from the actual pizza price for each observed pizza purchase.

The magnitude of each residual indicates how much you’ve over- or under- predicted the pizza price, or prediction error.

Note the green lines in the plot below:

Residuals

The residuals, or vertical distances, are shown here in green. (Created in Shiny)

Lloyd learns about residuals

Recall, the least-squares regression equation:

pizza price = 1.25(toppings) + 15

Lloyd says he can predict the price of a pizza with 12 toppings:

pizza price =1.25*12 + 15

pizza price = $30

Sure, it’s easy to take the model and run with it. But what if the customer ordered 12 PREMIUM toppings? Logic says that’s (1.50)*12 + 15 = $33.

You explain to Lloyd that the residual here is 33 – 30, or $3. When a customer orders a pizza with 12 premium toppings, the model UNDER predicts the price of the pizza by $3.

lloyd christmas

How valuable is THIS model for prediction purposes? Answer: It depends how much error is acceptable to your business and to your customer.

Why the Residuals Matter

To determine if a linear model is appropriate, protocol* says to create a residual plot and check the graph of residuals. That is, graph all x-values (# of toppings) against the residuals and look for any obvious patterns. Create a residual plot with your own data here.

Ideally, the graph will show a cloud of points with no pattern. Patterns in residual plots suggest a linear model may NOT be suitable for prediction purposes.

Shiny Residual Plot 2

I spy a pattern. Or, how I bubbled my answers in Sociology class.

You notice from the residual plot above, as the number of toppings increase, the residuals increase. You realize the prediction error increases as we predict for more toppings. For Pearson’s Pizza, the least-squares regression line may not be very helpful for predicting price from toppings as the number of toppings increases.

Is a residual plot necessary? Not always. The residual plot merely “zooms in” on the pattern surrounding the prediction line. Becoming more aware of residuals and the part they play in determining model fit helps you look for these patterns in the original plots. In larger data sets with more variability, however, patterns may be difficult to find.

Lloyd says, “But the p-value is significant. It’s < 0.0001. Why look at the visualization of the residual plot when the p-value is so low?”

Is Lloyd correct?! Find out in Part 3 of this series.

Summary

Today Lloyd learned a regression line has adds little to no value to his visualization if it won’t help him predict pizza prices from the number of toppings ordered.

As the owner of a prestigious pizza joint, you realize the importance of visualizing both the scatterplot and the residual plot instead of flying blind with correlation, R-Squared, and p-values alone.

Understanding residuals is one key to determining the success of your regression model. When you decide to use a regression line, keep your ultimate business goals in mind – apply the model, check the residual plot, calculate specific residuals to judge prediction error. Use context to decide how much faith to place in the magical maths.

linear_regression cartoon

*Full list of assumptions to be checked for the use of linear regression and how to check them here.

Want to have your own least-squares fun? This Rossman-Chance applet provides hours of entertainment for your bivariate needs.

—Anna Foard is a Business Development Consultant at Velocity Group

The Analytics PAIN: How to Interpret Trend Lines and Greek Letters

The Basics

Let’s say you own Pearson’s Pizza, a local pizza joint. You hire your nephew Lloyd to run the place, but you don’t exactly trust Lloyd’s math skills. So, to make it easier on the both of you, you price pizza at $15 and each topping at $1.

On a scatterplot you see a positive, linear pattern:

pizza1

Since the price of the pizza increases by $1 for each additional topping, that $1 per topping is quite literally the slope of the line of best fit.

Interpreting Software Output

Trend lines are used for prediction purposes (more on that later). In this example, you wouldn’t need a trend line to determine the cost of a pizza with, say, 10 toppings. But let’s say Lloyd needs some math help and you dabble in the black art of statistics.

Most software calculates this line of best fit using a method to minimize the squared vertical distances from the points to that line (called least-squares regression). In the pizza parlor example, little is needed to find the line of best fit since the points line up perfectly.

pizza3

The Equation of the Trend Line…

…may take you back to 9th grade Algebra

y = mx +b

Price = 1*NumberofToppings + 15

The price of the pizza (y) depends on the the number of toppings ordered (x). The independent (x) variable is always multiplied by the slope of the line. Here, the slope is $1. For every additional topping, the price of the pizza is predicted to increase by $1.

The price of the pizza without any toppings is $15. In the equation above, 15 is the y-intercept –The price of a cheese pizza, to be more specific to the example.

We’ll also refer to this equation as the “linear model.”

R and R-Squared (or, The Coefficients of Confusion)

The second value listed is called R-squared. But before you interpret R-squared (R^2) for Lloyd, you need to give him an idea of R since R-Squared is based on R.

R has many names: Pearson’s Coefficient, Pearson’s R, Pearson’s Product Moment, Correlation Coefficient

Why R? Pearson begins with a P…

No, Pearson wasn’t a Pirate. The Greek letter Ρ is called “Rho,” and translates to English as an “R”.

Pearson’s R measures correlation – the strength and direction of a linear relationship. Emphasis on LINEAR.

guideline-for-interpreting-correlation-coefficient-2-638

-From LinkedIn Learning

Since R-Squared = 1, you’ve probably figured out R = √1, or ±1. Positive 1 here, since there is a positive association between number of toppings and price. There is a perfect positive correlation between the number of toppings ordered and the price of the pizza.

Since the price of pizza goes up as the number of toppings increases, the slope is positive and therefore the correlation coefficient is positive (there is a mathematical relationship between the two – not going to bore you with the calculations). It is interesting to note the calculation for correlation does not distinguish between independent and dependent variables — that means, mathematically, correlation does not imply causation*.

The p-value of this output tells you the significance of the association between the two variables – specifically, the slope. Did the slope of 1 happen by chance? No, not at all. It’s significant because the two variables are associated in a perfectly linear pattern. This particular software gives “N/A” in this situation, but other software will give p < 0.000000. (P-values deserve their own blog post – no room here.)

R-Squared has another name: The coefficient of determination

Often you’ll hear R-Squared reported as a %. In this case, R-Squared = 100%. So why is R-Squared 100% here? Look at the graph – no points stray from the line! There is absolutely no variability (differences) whatsoever between the actual points and the linear model! Which makes it easy to understand the interpretation of R-Squared here:

100% of the variability (differences) in pizza prices can be explained by the different number of toppings.

Hearing this, you tell Lloyd that R-Squared tells us how useful this linear equation is for predicting pizza prices from number of toppings.

But in real life…R-Squared is NOT 100%.

Business Complications

Problem: Your customers start asking for “gourmet” toppings. And to profit, you’ll have to charge $1.50 for these gourmet toppings. You’ll still offer the $1 “regular” toppings as well.

Now, the relationship between a pizza’s price and number of toppings could vary substantially:

pizza4

Lloyd is gonna freak.

As the number of toppings increase, there is more and more dispersion of points along the line. That’s because the combination of regular and gourmet toppings differs more with as number of toppings increase.

Lloyd says a customer wants 4 toppings. He forgot to write down exactly which toppings. Four regular toppings will come to $19. But 4 gourmet toppings is a little pricier at $21. The prediction line says it’s $20. We’re only within a couple dollars, but that’s a good bit of variability. Over time, Pearson’s Pizza may lose money or piss off customers (losing more money) if Lloyd chooses the prediction line over getting the order right.

R-Squared (Again):

It’s all about VARIABILITY – the differences between the actual points and the line. And this is why predicting with a trend line is to be done with caution:

89.29% of the variability (differences) in pizza prices can be explained by the different number of toppings. Other reasons (like the type of topping chosen) cause the price differences, not just the number of toppings.

What R-Squared isn’t:

And that doesn’t mean the model will get it right 89.29% of the time (it’s not a probability). R-Squared also doesn’t tell us the percent of the points the line goes through (a common misunderstanding).

Non-linear Models – 3 Warnings

How does gas mileage change as your car speed increases?

Gas1

Even though we can see the points are not linear, let’s slap a trend line on there to make certain, for LOLs:

Gas2

Hint: Horizontal trend lines tell you NOTHING. If slope = 0, R = 0.

And now you also understand why the R-squared value is equal to 0:

0% of the variability in gas mileage can be explained by the change in speed of the vehicle.

Wait a second…

CLEARLY there is a relationship! AKA, Why we visualize our data and don’t trust the the naked stats.

Mathematically, the trick is to “transform” the curve into a line to find the appropriate model. It typically involves logarithms, square roots, or the reciprocal of a predictor variable.

kevin hart

I won’t do that here.



Gas3

As you can see, technology is amazing and created this model from a 3rd degree polynomial…

Warning #1

Which is TOTALLY FINE if you’re going to interpolate – predict for mileage only between the speeds of 20 and 60 mph. In case you are wondering why you wouldn’t extrapolate – predict for speeds outside the 20 – 60 mph range, I brought in a special guest.

bill nye



Third degree polynomials have 2 turns:



Gas5

The full gas mileage vs. speed model. This is not the model you thought you were dating.

The R-Squared value here is 0.9920 – this value is based on the transformed data (when the software temporarily made it linear behind your back). Remember the part about R (and therefore R-Squared) describing only LINEAR models? The R-Squared is still helpful in determining a model fit, but context changes a bit to reflect the mathematical operations used to make the fit. So use R-Squared as a guide, but the interpretation isn’t going to make sense in the context of the original variables anymore. Though no need to worry about all that if you stick to interpolation!

Warnings #2 and #3

What if my software uses nonlinear regression?

This can get confusing so I’ll keep it brief. Full disclosure: I thought nonlinear regression and curve-fitting with linear regression yielded the same interpretation until Ben Jones pointed out my mistake!

R-Squared does NOT make sense for nonlinear regression. R-Squared is mathematically inaccurate for nonlinear models and can lead to erroneous conclusions. Many statistical software packages won’t include R-Squared for nonlinear models – please ignore it if your software kicks it out to you.

Consequently, ignore the p-value for nonlinear regression models as well – the p-value is based on an association using Pearson’s R, which is robust for linear relationships only.

The explanation of warnings 2 and 3 are beyond the scope of this post – but if you’d like to learn more about the “why,” let me know!

Thanks for sticking around until the end. Send me a message if you have a suggestion for the next topic!

*Even though number of toppings does cause the price to increase in this use case, we cannot apply that logic to correlation universally. Since correlation does not differentiate between the independent and dependent variables, the correlation value itself could erroneously suggest pizza prices cause the number of toppings to increase.

Bonus Resource: An excellent video I found explaining R-squared using a similar pizza example! If what I said still leaves you confused, Mr. Nystrom will certainly give you pizza mind!

—Anna Foard is a Business Development Consultant at Velocity Group

5 Things Teaching Taught Me



5 years of letters from students

5 years of letters from students

159 days ago, I turned in my classroom keys, signed away by school ID badge, and left teaching.

159 days of growth and change. And though I won’t get into the “why” details here, I must emphasize my reasons for leaving the classroom after 14 years had nothing to do with the students or the teaching.

Today, I took some time to go through a pile of letters from my kids over the most recent 5 years and reflect on what these beautiful minds taught me.



1) Everyone has a back story. Be kind.

I’m starting with the hardest one first — but hear me out.

It’s easy to dislike people. People suck. Especially in groups. (But keep in mind, you probably have sucked once or twice in your life to someone else, too.) And it’s even easier to find contempt for people you don’t know.

IMG_20180524_190959620But EVERYONE has a story.

I’ve met kids from all walks of life. Some had already been incarcerated when I met them. Others are in prison now. I’ve been threatened within the inch of my life. I’ve been cursed at, spit at, and ignored. As I grew as a teacher I found my only play is respond with kindness and compassion.

Why?

Because everyone has a story. And when kids are angry or hurting, they respond in the way you’d expect them to respond – teeth clenched, ready to take you on. I can’t teach you the multiplicative inverse of π/4 if you’ve got something significant weighing on your mind. (I’ll get into specific stories in a bit.)

Teachers spend a considerable amount of time developing relationships, the actual “teaching” plays a minor role. You learn to love on the kids like they are your own, you give them a safe place, and you think about them when they’re out of your sight.

True story: I once let a girl shove me into a set of lockers to give my student enough time to run away from a fight.

I’ve only spent 159 days around adults so far this year so I am no expert in that field; however, I’ve found they respond surprisingly well to a smile. At times I’ve noticed kindness is not what folks expect, and it disarms their defensiveness. (Note: Manipulative people know this too, which makes it hard for the most cynical of cynics to trust kindness. But be kind anyway.)

img_20181030_181926848

2) Listen.

If the first thing I learned is everyone has a story, then the second thing I discovered is to listen to those stories – some unfold like an epic narrative, while others are short and comical.

But every individual has a unique perspective, a different life experience from you. They may have just walked down a road you don’t realize you’ll be on next week. Maybe they DO know something you don’t?

Over the past 159 days, I’ve met so many beautiful people and listened to their stories. Instead of relearning the business world by taking another business class, I met with friends and strangers, asking them questions about themselves and their day-to-day jobs.  Surprisingly, where I have ended up in my job has everything to do with the conversations I had along the way.

I learned how to listen from my students. Often they would come to me to externally process some high school situation. Other times, though, they needed a confidant. Every interaction has grown my knowledge in some positive way. Listening to students taught me how to deal with serious situations and how to connect someone else’s experiences to my own. Listening grew my empathy. And even negative interactions will develop your character if you allow yourself to grow from the challenge.





img_20181030_182026641

3) People want someone to believe in them.

I’ll never forget a particular student in my Geometry class from a couple years ago. He was behind in school, on probation, no parental support, and on the edge of getting expelled. I noticed he didn’t struggle in math, his struggle was with life. And deep down, this wasn’t the life he wanted. Following lesson #1, I gave him a little room to decompress when he’d had a rough day. I left him alone when he was angry (except, when no one was looking, I’d give him a nod). I praised his work, I let him challenge me, and when I eventually gained his trust, I challenged him back. During my planning period he took to stopping by room just to chat — he liked to drop some F-bombs just to see what I would do, other times he’d sit down and vent, but mostly just tell me how much he wanted to graduate.

He just wanted someone to listen.

I gave him more chances than most to make up tests so he could pass the class. I did. I totally broke the rules right there – and I don’t regret it. Because I believed in him. Again, it was his daily life, not his intelligence, keeping his grades low.

But one day, as I watched from the window, he left school, got on his motorcycle, and took off. The administrator there told me the student had just DROPPED OUT. “He’ll probably be dead in ten years,” the admin scoffed. (WTF.)

Fast forward a year and a half later: This student walked across the stage at graduation. He’d come back, made up all his classes, and graduated with his class on time. Luckily, I wasn’t the only person who’d believed in him and someone else led him through the finish line. I cried ugly tears on that graduation day, May 2018.

img_20181030_181856876

4. Relationships matter.

For those in the back: ABOVE ALL ELSE, it’s about the relationships

IMG_20180524_190813353

.

Ask any teacher worth their salt and they will echo my sentiment. This job is NOT about test scores – these kids are not data points. This job is not about winning sporting or academic events. Teaching is about forming bonds and making connections.

Over my 14-year tenure, I not only taught in a classroom, I also coached girls’ cross-country in my early years, then the academic bowl team. I spent the last 5 years I advising the senior class.

One day, I may no longer have a job, a house, a Twitter following. I’m sure I’ll be fine. But if I am not surrounded by the people I love, I have failed those people. I refuse to allow myself to be measured by my job title or social standing. Instead I prefer to leave a legacy built on the relationships I’ve forged and inspired by the people who have influenced me.

img_20181030_181959253

5. Forgive yourself.

This one I’m still learning.

Nothing ever goes as planned in teaching. You’ve got to be flexible, stay on the ball. Whatever magic dance you dance the night before a high-stakes test never seems to yield the results the lawmakers/shareholders/naysayers want. And because the “squeaky wheel gets the grease,” those of us with the pedal to the metal are offered no encouragement from above. It’s disheartening to only hear negative from the adults in the room.

To top it off, I would leave work every day feeling guilty because I felt I hadn’t done enough for my students, and feeling even more guilt that I hadn’t yet picked my own children up from school.

But then the kids… The kids would walk in my classroom, tell me their stories of the day. If I had been absent, they asked where I’d been. They’d write me letters year in and year out. The kids. The kids encourage ME. The kids teach me I should go easy on myself.

159 days away from the classroom. As I said, this one I’m still learning. I’m only human.

img_20181030_181725216img_20181030_181937060

Using Tableau to Improve Individual Student Learning

Fact: Educators must use student data to increase student learning.

Fact: Educators must produce data evidence that they did, in fact, attempt to increase student learning.

Fact: Educators compare class averages (means) on summative assessments to determine test reliability and student learning.

Fact: Test validity is rarely discussed.

Fact: Most data sets (class size) are small sample sizes with huge variations in classroom demographics between classes (even period to period with the same teacher)

This article is dated; however, these are present and real problems within school districts.

As you know, adults are resistant to change. Teachers are asked to produce data but given minimal training outside of “compare average test scores”. And without a math background, this may even make sense to those educators and superintendents. Therefore, when it’s easier to compare a mean and it cleans up the mandatory paperwork faster, this is the way things are done.
Question: How will (only) comparing averaging actually help individual student learning?
Question: If teachers lack a background of statistics and, even more frustrating for the educator, lack the time to learn the basics, how will they begin to leverage their own student data to improve learning? Ultimately, it is what they WANT to do. But how?
Solution: Educators need to answer deeper questions about their students using data without additional statistical training all while using their time efficiently. It must also be priced for teachers: free. And it’s here. It’s called Tableau. It’s data visualization. Instead of looking at a sea of numbers, Tableau produces pictures. Without a math background, anyone can look for trends and draw conclusions. And it’s free to educators.
 Data 4
Tableau allows teachers to import student gradebook data (most gradebooks export as a .CSV). Once the educator is in the Tableau workbook, one can merely hold down the CTRL key, click on whatever variables they would like to compare/explore. A “show me” set of suggested graphs pops up (if it doesn’t automatically pop up, after taking fingers off the keyboard, CTRL+1 will do the trick). You can also just drag and drop into the workbook. Drag and drop students to color. Play with it. And sometimes an ID will need to be set to a string (so the software knows you’re talking people, not calculations) and sometimes you’ll need to switch columns and rows for a better visual. I recommend sorting students by whatever measure (assessment? assignment? overall grade?) you are asking your data to compare. Playing with the visualization is a fun way of learning how to use the software. It won’t take long.
My first visualization
Unit 3 Tableau

Only a subset of the full visualization for 63 students. The bars show the student’s overall AP Stats performance through this unit.

This graphic sorts messy data from Unit 3 (The Linear Regression unit) into a clean, organized dashboard to help me compare my students’ formative and summative assessments (sorted on Unit Test score, ascending).
I was shocked to see the overall trend in the formative to summative scores: They went DOWN. And they shouldn’t. And that’s a validity problem from my end. But this was not so evident in looking at the aggregate data. A t-test would tell me there is “no significant difference” between quiz and test scores. But we’re talking individuals, my students. And my job is to GROW them. By looking within the data, I found trends about which types of students, for example, lost traction from quiz to test. And my ultimate conclusion was to take ownership on my end. (This could be another post for another day.)
After playing with Tableau some more, I realized rows worked better than columns for the above visualization.
And did you know that approximately 8 percent of men and 0.5 percent of women are red/green colorblind?
So my next 2 units looked more like this:
Unit 5 Tableau
To support our school’s mission and vision, I began teaching other teachers how to leverage student data within their PLCs to draw meaningful conclusions about teacher methods and student learning with Tableau. And these teachers are excited to identify trends and answer deeper student needs questions – to ultimately help and grow each individual student.
It is time teachers stop looking only to aggregate data and averages. We need the tools to find trends within each student’s learning patterns in order to provide them with the best “differentiated” learning experience for them. Unfortunately, I have found there is a huge gap between what districts want and what teachers are asked to do.
Some school districts have already figured this out. – Yes, that includes Atlanta Public Schools. Teachers have access to their student data through dashboards with a click of a button. And not only do they use it, they find value in the data visualization.
Eventually, data dashboards that ultimately give teachers a visualization of their current student data, including growth and achievement data, is the future of education. Right now teachers who want this will have to figure out the software (thankfully, Tableau is easy to use for simple visualizations.) But ultimately, data visualization through dashboards are the next step in the journey.
The beginnings of my data dashboard:
data 1
data 2
data 3
